MECH 36 PISTON ROD SEAL

ITEM ITEM NO MECH CODE DIMENSION
PISTON-ROD SEAL MECH36 MECH36-004 4.76X12.70X6.35
PISTON-ROD SEAL MECH36 MECH36-010 10 X 17 X 6,3
PISTON-ROD SEAL MECH36 MECH36-010/1 10 X 19 X 6,3
PISTON-ROD SEAL MECH36 MECH36-012 12 X 20 X 6,3
PISTON-ROD SEAL MECH36 MECH36-014 14 X 22 X 6,3
PISTON-ROD SEAL MECH36 MECH36-014/1 14 X 22 X 7
PISTON-ROD SEAL MECH36 MECH36-015 15 X 23 X 6,3
PISTON-ROD SEAL MECH36 MECH36-016 16 X 24 X 6,3
PISTON-ROD SEAL MECH36 MECH36-016/1 16 X 24 X 6,5
PISTON-ROD SEAL MECH36 MECH36-016/2 16 X 24 X 7
PISTON-ROD SEAL MECH36 MECH36-018 18 X 26 X 6,3
PISTON-ROD SEAL MECH36 MECH36-018/1 18 X 24 X 5,2
PISTON-ROD SEAL MECH36 MECH36-019 19,5 X 27,5 X 8.3
PISTON-ROD SEAL MECH36 MECH36-020 20 X 28 X 6,3
PISTON-ROD SEAL MECH36 MECH36-020/1 20 X 26 X 5,5
PISTON-ROD SEAL MECH36 MECH36-020/2 20 X 27 X 6,5
PISTON-ROD SEAL MECH36 MECH36-020/3 20 X 28 X 7
PISTON-ROD SEAL MECH36 MECH36-020/4 20 X 30 X 8,5
PISTON-ROD SEAL MECH36 MECH36-022 22 X 30 X 6,3
PISTON-ROD SEAL MECH36 MECH36-022/1 22 X 30 X 6,5
PISTON-ROD SEAL MECH36 MECH36-022/2 22 X 30 X 7
PISTON-ROD SEAL MECH36 MECH36-022/3 22 X 32 X 7.3
PISTON-ROD SEAL MECH36 MECH36-025 25 X 32 X 6,3
PISTON-ROD SEAL MECH36 MECH36-025/1 25 X 33 X 6,3
PISTON-ROD SEAL MECH36 MECH36-025/2 25 X 33 X 6
PISTON-ROD SEAL MECH36 MECH36-025/3 25 X 35 X 8,3
PISTON-ROD SEAL MECH36 MECH36-025/4 25 X 33 X 6,4
PISTON-ROD SEAL MECH36 MECH36-025/5 25 X 35 X 9
PISTON-ROD SEAL MECH36 MECH36-028 28 X 36 X 6,3
PISTON-ROD SEAL MECH36 MECH36-028/1 28 X 43 X 11
PISTON-ROD SEAL MECH36 MECH36-028/2 28 X 35 X 4.5
PISTON-ROD SEAL MECH36 MECH36-028/3 28 X 36 X 6,4
PISTON-ROD SEAL MECH36 MECH36-028/4 28,57 X 41,27 X 10
PISTON-ROD SEAL MECH36 MECH36-030 30 X 38 X 6,3
PISTON-ROD SEAL MECH36 MECH36-030/1 30 X 38 X 6
PISTON-ROD SEAL MECH36 MECH36-030/2 30 X 40 X 6,3
PISTON-ROD SEAL MECH36 MECH36-030/3 30 X 40 X 7,5
PISTON-ROD SEAL MECH36 MECH36-030/4 30 X 40 X 7
PISTON-ROD SEAL MECH36 MECH36-030/5 30 X 50 X 14.5
PISTON-ROD SEAL MECH36 MECH36-030/6 30 X 38 X 6,4
PISTON-ROD SEAL MECH36 MECH36-030/7 30 X 37,5 X 6,5
PISTON-ROD SEAL MECH36 MECH36-031 31,75 X 47,62 X 11,6
PISTON-ROD SEAL MECH36 MECH36-032 32 X 40 X 6,3
PISTON-ROD SEAL MECH36 MECH36-032/1 32 X 44 X 12,5
PISTON-ROD SEAL MECH36 MECH36-035 35 X 43 X 6,3
PISTON-ROD SEAL MECH36 MECH36-035/1 35 X 45 X 8
PISTON-ROD SEAL MECH36 MECH36-035/2 35 X 43 X 6
PISTON-ROD SEAL MECH36 MECH36-035/3 35 X 50 X 11,5
PISTON-ROD SEAL MECH36 MECH36-035/4 35 X 43 X 6,5
PISTON-ROD SEAL MECH36 MECH36-035/5 35 X 43 X 7.3
PISTON-ROD SEAL MECH36 MECH36-036 36 X 44 X 6,3
PISTON-ROD SEAL MECH36 MECH36-036/1 36 X 51 X 11
PISTON-ROD SEAL MECH36 MECH36-038 38 X 50 X 9.5
PISTON-ROD SEAL MECH36 MECH36-038/1 38,1 X 50,8 X 12,4
PISTON-ROD SEAL MECH36 MECH36-040 40 X 48 X 6,3
PISTON-ROD SEAL MECH36 MECH36-040/1 40 X 50 X 8
PISTON-ROD SEAL MECH36 MECH36-040/2 40 X 48 X 8
PISTON-ROD SEAL MECH36 MECH36-040/3 40 X 50 X 7
PISTON-ROD SEAL MECH36 MECH36-040/4 40 X 48 X 6,5
PISTON-ROD SEAL MECH36 MECH36-040/5 40 X 60 X 14,5
PISTON-ROD SEAL MECH36 MECH36-040/6 40 X 50 X 11
PISTON-ROD SEAL MECH36 MECH36-040/7 40 X 48 X 7.3
PISTON-ROD SEAL MECH36 MECH36-042 42 X 50 X 6,3
PISTON-ROD SEAL MECH36 MECH36-045 45 X 53 X 8,5
PISTON-ROD SEAL MECH36 MECH36-045/1 45 X 55 X 8
PISTON-ROD SEAL MECH36 MECH36-045/2 45 X 55 X 10,5
PISTON-ROD SEAL MECH36 MECH36-045/3 45 X 60 X 11
PISTON-ROD SEAL MECH36 MECH36-045/4 45 X 57 X 9.5
PISTON-ROD SEAL MECH36 MECH36-045/5 45 X 65 X 14,5
PISTON-ROD SEAL MECH36 MECH36-045/6 45 X 53 X 6.3
PISTON-ROD SEAL MECH36 MECH36-046 46 X 56 X 8
PISTON-ROD SEAL MECH36 MECH36-048 48 X 60 X 10
PISTON-ROD SEAL MECH36 MECH36-050 50 X 62 X 9,5
PISTON-ROD SEAL MECH36 MECH36-050/1 50 X 60 X 7,5
PISTON-ROD SEAL MECH36 MECH36-050/2 50 X 60 X 8
PISTON-ROD SEAL MECH36 MECH36-050/3 50 X 60 X 10
PISTON-ROD SEAL MECH36 MECH36-050/4 50 X 70 X 14,5
PISTON-ROD SEAL MECH36 MECH36-055 55 X 65 X 8
PISTON-ROD SEAL MECH36 MECH36-055/1 55 X 67 X 10,5
PISTON-ROD SEAL MECH36 MECH36-055/2 55 X 70 X 10,5
PISTON-ROD SEAL MECH36 MECH36-055/3 55 X 63 X 8.3
PISTON-ROD SEAL MECH36 MECH36-056 56 X 66 X 8
PISTON-ROD SEAL MECH36 MECH36-056/1 56 X 76 X 14
PISTON-ROD SEAL MECH36 MECH36-060 60 X 70 X 8
PISTON-ROD SEAL MECH36 MECH36-060/1 60 X 70 X 7,5
PISTON-ROD SEAL MECH36 MECH36-060/2 60 X 72 X 9.5
PISTON-ROD SEAL MECH36 MECH36-060/3 60 X 80 X 12.5
PISTON-ROD SEAL MECH36 MECH36-060/4 60 X 72 X 10
PISTON-ROD SEAL MECH36 MECH36-060/5 60 X 75 X 13
PISTON-ROD SEAL MECH36 MECH36-060/6 60 X 80 X 14,5
PISTON-ROD SEAL MECH36 MECH36-063 63,5 X 82,55 X 14,28
PISTON-ROD SEAL MECH36 MECH36-065 65 X 73 X 9,6
PISTON-ROD SEAL MECH36 MECH36-065/1 65 X 77 X 9,6
PISTON-ROD SEAL MECH36 MECH36-070 70 X 80 X 7,5
PISTON-ROD SEAL MECH36 MECH36-070/1 70 X 82 X 9,6
PISTON-ROD SEAL MECH36 MECH36-070/2 70 X 82 X 9
PISTON-ROD SEAL MECH36 MECH36-070/3 70 X 90 X 14
PISTON-ROD SEAL MECH36 MECH36-070/4 70 X 85 X 8
PISTON-ROD SEAL MECH36 MECH36-070/5 70 X 80 X 8
PISTON-ROD SEAL MECH36 MECH36-070/6 70 X 85 X 12
PISTON-ROD SEAL MECH36 MECH36-075 75 X 87 X 9,3
PISTON-ROD SEAL MECH36 MECH36-075/1 75 X 85 X 8
PISTON-ROD SEAL MECH36 MECH36-080 80 X 92 X 9,6
PISTON-ROD SEAL MECH36 MECH36-080/1 80 X 96 X 10
PISTON-ROD SEAL MECH36 MECH36-080/2 80 X 92 X 9
PISTON-ROD SEAL MECH36 MECH36-080/3 80 X 90 X 8
PISTON-ROD SEAL MECH36 MECH36-085 85 X 97 X 9,6
PISTON-ROD SEAL MECH36 MECH36-090 90 X 102 X 9,6
PISTON-ROD SEAL MECH36 MECH36-090/1 90 X 110 X 12.5
PISTON-ROD SEAL MECH36 MECH36-100 100 X 115 X 12
PISTON-ROD SEAL MECH36 MECH36-100/1 100 X 120 X 14
PISTON-ROD SEAL MECH36 MECH36-110 110 X 125 X 12
PISTON-ROD SEAL MECH36 MECH36-110/1 110 X 130 X 12

PISTON ROD SEAL

Our MECH36 type of seal has a compact structure consisting of NBR impregnated fabric and 80 shore A NBR. Having high tensile strength NBR impregnated fabric prevents the possible permissible gap during operation. Being used as single acting seal in applications both for piston and rod, MECH36 type of seal can be used safely in a pressure 250 Bar.

"For need out of standard dimensions, please apply our customer service.”
