Stock of PU Products

RODS ( Round Sections )

Used as strippers, pressure cylinders in bulging apps as tube bending mandrels+for machining variety of parts

Standard Lengths are : 6″, 12″, 24″ , 36″ and 48″

Hardnesses : 20A, 30A, 40A, 60A, 70A, 80A, 90A, 95A, and 75D

Standard Colors : Amber or Black ( Other Colors Available )

Diameter Tolerance Diameter Tolerance
1/4 “ + 0.025 “ 1-1/2 “ + 0.050 “
3/8 “ + 0.025 “ 1-5/8 “ + 0.050 “
1/2 “ + 0.025 “ 1-3/4 “ + 0.050 “
5/8 “ + 0.025 “ 2 “ + 0.050 “
3/4 “ + 0.025 “ 2-1/4 “ + 0.050 “
7/8 “ + 0.025 “ 2-1/2 “ + 0.050 “
1 “ + 0.025 “ 3 “ + 0.050 “
1-1/8 “ + 0.050 “ 3-1/2 “ +/- 2 %
1-1/4 “ + 0.050 “ 4 “ +/- 2 %
1-3/8 “ + 0.050 “ 5“ +/- 2 %

TUBES ( Hollow Sections )

Standard Lengths : 12″, 24″, 36″

Hardnesses : 20A, 30A, 40A, 60A, 70A, 80A, 90A, 95A, and 75D

Standard Colors : Amber or Black (Other Colors Available )

Tolerance I.D : + 0.010″ , – 0.060″ ; O.D : + 0.060″ , – 0.010″

I.D O.D I.D O.D
1 “ 1-3/4 “ 2-1/4 “ 3 “
1/2 “ 2 “ 1-3/4 “ 3-1/4 “
1 “ 2 “ 2-1/4 “ 3-1/4 “
1-1/4 “ 2 “ 1-1/4 “ 3-1/2 “
1-1/2 “ 2 “ 2 “ 3-1/2 “
1/2 “ 2-1/2 “ 2-1/2 “ 3-1/2 “
1 “ 2-1/2 “ 2-3/4 “ 3-1/2 “
1-1/4 “ 2-1/2 “ 2-3/4 “ 3-3/4 “
1-1/2 “ 2-1/2 “ 2 “ 4 “
1-1/4 “ 2-3/4 “ 2-1/4 ” 4 “
1-1/2 “ 2-3/4 “ 2-1/2 “ 4 “
1-3/4 “ 2-3/4 “ 3 ” 4 “
2 “ 2-3/4 “ 2-1/2 “ 4-1/2 “
2-1/2 “ 2-3/4 “ 3 “ 4-1/2 “
1 “ 3 “ 3 “ 5 “
1-1/2 “ 3 “ 4 “ 5-1/2 “
2 “ 3 “ 5 “ 6 “

BARS ( Square and Rectangular Sections )

  • * Molded to shape+used as Die-Pads in bending apps.
  • * Used as bottom dies for scratch-free bending.

Standard Lengths are : 12″, 24″, 36″, 48″

Hardnesses : 20A, 30A, 40A, 60A, 70A, 80A, 90A, 95A, and 75D

Standard Colors : Amber or Black (Other Colors Available )

Size ( Width x Height ) Tolerance Size ( Width x Height ) Tolerance
1/2 ” x 1/2″ * – 0.015 “ 2 ” x 2 “ – 0.075 “
3/4 ” x 3/4 “ – 0.015 “ 2 ” x 3 “ – 0.075 “
1″ x 1″ – 0.025 “ 3 ” x 3 “ +/- 2%
1-1/4 ” x 1-1/4 “ – 0.050″ 4 ” x 4 “ +/- 2%
1-1/2 ” x 1-1/2 “ – 0.075 “ 4 ” x 5 “ +/- 2%

SHEETS ( Flat Sections up to 2″ Thickness)

  • * Layered in a retainer offer multiple working surfaces
  • * more penetration for radius bends

Standard Lengths are : 12″W x 12″L, 12″x 24″, 24″ x 24″, 12″ x 48″L, 24″ x 48″ L

Hardnesses : 20A, 30A, 40A, 60A, 70A, 80A, 90A, 95A, and 75D

Standard Colors : Amber or Black (Other Colors Available)

Thickness Tolerance Thickness Tolerance
1/16 ” +/- 0.010 “ 7/8 “ +/- 0.025 “
1/8 “ +/- 0.010 “ 1 “ +/- 0.025 “
3/16 ” +/- 0.010 “ 1 -1/4 “ +/- 0.035 “
1/4 ” +/- 0.015 “ 1-1/2 “ +/- 0.035 “
3/8 “ +/- 0.015 “ 1-3/4 “ +/- 0.035 “
1/2 “ +/- 0.025 “ 2 “ +/- 0.035 “
5/8 “ +/- 0.025 “ 2-1/2 “ +/- 0.050 “
3/4 “ +/- 0.025 “ 3 “ +/- 0.050 “

Refer technical data for designing and application of rubber products
